QSS2901

Film Scanner &Printer(SMP-1700) Exposure engine: MLVA engine Print resolution: 400 dpi Exposure speed: 25.4 mm/sec Light source of printer: Halogen lamp(30.5v,370w) Image import method: Main scanning: Independent RGB measurement via 3 lines CCD Sub scanning: Scanning by film movement. Film types: Negative and positive(135,120,1X240), mounted positives. Film size: 135F,135P, 135H, 135HD, 120(6X4.5,6X6,6X7,6X8, 6X9), 1X240, 110 Film carrier(Option): 135/240 AFC: Compatible with both 135 and 1X240 film Lane chages performed manually,Minimum film length: 2 frames 120 AFC: Film carrier for 120 film. Compatible with negatives and positives. Minimum film length:2 frames 110 AFC: Film carrier for 110 film. Compatible with negatives and positives. Minimum film length:3 frames 135/240 MMC: Carrier for mounted 135 and 1X240 film. Compatible with positives only. Input source: Standard:FD,CD-ROM, CD-R/RW Option: MO, Zip, DVD-Rom, DVD-R,DVD-RAM, CompactFlash, SmartMedia, PC card, Memeory Stick, SD Card, Flatbed scanner Output media: Standard:FD Option: CD-R/RW, MO, Zip, DVD-RAM, CompactFlash, SmartMedia, PC card, Memory Stick, SD Card Color correction keys: Range: From –15 to +15 Difference ratio: From 0.1% to 50.0% (Adjustable in units of 0.1%) The standard ratio is 5.8% Density correction keys: Range: From –15 to +15 Difference ratio: From 0.1% to 50.0% (Adjustable in units of 0.1%) The standard ratio is 15.0% Repeat Printing: Any number up to 999 prints. Channels:99 channels Operation section: Keyboard for scanning and printing. Keyboard and mouse for image editing. Display monitor: 17 inch color display monitor(Viewing angle is adjustable) Monitor display: Final print condition displayed on monitor as a positive image (A maximum of 40 frames can be displayed at one time) Operation directions, settings, error information, etc, are displayed in dialogue from. Ample explanations and help functions for each mode. Control with the built-in colorimeter. Paper Processor(PP-1216) Print sizes: Paper width:82.5, 89, 102, 114, 117, 120, 127, 130, 152, 165, 178, 203, 210, 216, 240, 279, 305(mm) Paper advance length:82.5 to 457.0 mm Paper supply: Dual magazine system. Paper specifications: Maximum diameter of paper roll: 250mm, paper length:180M, Emulsion side OUT only. Transport system: Roller transport Circulation pumps: Corrosion resistant magnetic pumps with sensors to detect pump rotation. Temperature control: Temperature in each sub-tank is controlled separately. Replenishment system: An inner mixing device is installed. The machine calculates the amount of paper processed and automatically supplies the appropriate amount of replenisher to each tank. Water refilling: Water refilling is carried out automatically when the solution level sensors are activated. Automatic cleaning: The upper guide is automatically cleaned at close down checks. Collection of waste solutions: Three individual waste solutions are drained and collected into each tank separately. Dryer: Hot air blowing system. Automatic on/off to save power. Order classification: Can handle prints up to 152mm in width and 305mm in length. Maximum number of orders: 17 orders (50 prints/order) 14 orders(82 prints/order) The customer can choose either 17 orders or 14 orders Processing speed: 1638 mm/min Heating capacity: Max 3.6KW(3,100kcal/h) Dimensions: See “External view” below Weight: Approx. 692kg(Main body) + Approx. 143kg(Solution)= Approx.835kg
